Specification
|
Model No.
|
WIT 50H/WIT 50K-HU
|
WIT 63K-H/WIT 63K-HU
|
WIT 75K-H/ WIT 75K-HU
|
WIT100K-H/ WIT 100K-HU
|
|
Warranty
|
||||
|
Product Warranty (Min)
|
5 Years
|
5 Years
|
5 Years
|
5 Years
|
|
Input Data(DC)
|
||||
|
Max. DC Power
|
109.2 kW
|
124.8 kW
|
156 kW
|
156 kW
|
|
Max. DC Voltage
|
1100 V
|
1100 V
|
1100 V
|
1100 V
|
|
Nominal DC Voltage
|
550 V
|
550 V
|
550 V
|
550 V
|
|
Min. DC Voltage to Start Feed In
|
195 V
|
195 V
|
195 V
|
195 V
|
|
Max. DC Current
|
224 A
|
256 A
|
320 A
|
320 A
|
|
MPP(T) Voltage Range
|
180~800 V
|
180~800 V
|
180~800 V
|
180~800 V
|
|
No of MPP Trackers
|
7
|
8
|
10
|
10
|
|
DC Inputs
|
14
|
16
|
20
|
20
|
|
Output Data (AC)
|
||||
|
Nominal AC Power
|
50 kW
|
63 kW
|
75 kW
|
100 kW
|
|
Nominal AC Voltage
|
380, 400, 415 V
|
380, 400, 415 V
|
380, 400, 415 V
|
380, 400, 415 V
|
|
Frequency Range
|
45-65 Hz
|
45-65 Hz
|
45-65 Hz
|
45-65 Hz
|
|
Frequency
|
50, 60 Hz
|
50, 60 Hz
|
50, 60 Hz
|
50, 60 Hz
|
|
Distortion (THD)
|
< 3 %
|
< 3 %
|
< 3 %
|
< 3 %
|
|
No of feed-in phases
|
3
|
3
|
3
|
3
|
|
Max. Efficiency
|
98%
|
98%
|
98%
|
98%
|
|
General Data
|
||||
|
Dimensions (H/W/D)
|
1350x820x510 mm
|
1350x820x510 mm
|
1350x820x510 mm
|
1350x820x510 mm
|
|
Weight
|
143 kg
|
143 kg
|
150 kg
|
150 kg
|
|
Operating Temperature
|
-30 ~ +60 ℃
|
|||
|
Transformer
|
Transformerless
|
|||
|
Protection Class
|
IP66
|
|||
|
Humidity
|
0-100 %
|
|||
|
Cooling
|
Fan
|
|||
|
Max. Altitude
|
4000 m
|
|||
|
Interface
|
RS 485, USB, WLAN
|
|||
|
Display
|
LED
|
|||
|
Protection Features
|
||||
|
Protection Features
|
Anti Island Protection(ENS), Short Circuit Protection, Residual Current Device (RCD), Reverse Polarity Protection, Surge Protection, Ground Fault Monitoring, Grid Monitoring
|
|||
