Home Use Micro Solar Inverters 400W 600W 800W 1000W Storage Power for Balcony System
*127V/220V, 133V/230V and 50/60Hz, single phase or split phase or Three phase system
*EU/US Stardard
*Power Range 300-2000W
Specifications of Micro Inverter
| MODEL | BDM 300 | BDM 400 | BDM 600 | BDM 600 LV | BDM 800 | BDM 1000 | BDM 2000 |
| PV INPUT DATA | |||||||
| Recommended PV Power Range | 450W | 600W | 450W*2 | 450W*2 | 600W*2 | 750W*2 | 750W*4 |
| MAX Input Voltage | 60Vdc | ||||||
| MPPT Voltage Range | 22-55Vdc | ||||||
| Max Input Current | 14A | 18A | 14A*2 | 14A*2 | 18A*2 | 18A*2 | 18A*4 |
| Overvoltage Protection Category | II | ||||||
| AC Output Data | |||||||
| Peak Output Power | 350W | 400W | 600W | 600W | 800W | 1000W | 2000W |
| Max. Continous Output Power | 350W | 400W | 600W | 600W | 800W | 1000W | 2000W |
| Rated Output Voltage | 230Vac | 127Vac | 230Vac | 230Vac | 230Vac | ||
|
Nominal Output Voltage Range
|
207 ~ 253VAC | 207 ~ 253VAC | 207 ~ 253VAC | 207 ~ 253VAC | |||
|
Nominal Frequency / Range
|
50/60hz | ||||||
| Max. Continous Output Current | 1.4A | 1.74A | 2.61A | 2.61A | 3.48A | 4.4A | 8.69A |
| Power Factor (Nominal/Adjustable Range) | >0.99(full load) | ||||||
| THDi@Rated Power | <5% | ||||||
| Overvoltage Protection Category | III | ||||||
| GENERAL DATA | |||||||
| MPPT Efficiency | >99.5% | ||||||
| Night Power Consumption | 110mW | ||||||
| Operating Ambient Temperature Range | -40℃~65℃ | ||||||
| Relative Humidity Range | 0-100% | ||||||
| Protection Class | IP67 | ||||||
| Warranty | 10Years | ||||||
| Monitoring | WIFI/PLC | ||||||
Package of Solar Micro Inverter
Porjects of Grid Tie Micro Inverter
One stop solution for solar power system.
For more information, please feel free to contact our team
Email:alice@shinewit.com
Whatsapp: +8615056568964
